GMRS / UHF No Ground Plane (NGP) Whip Antenna Kit & NMO Mount

SKU: ANT-SPARE-KIT-U
Regular price $98.00



Rugged Radios Antenna Tuning and Installation Guide



Simple kit combines what you need for antenna replacement in the field. Includes a powerful magnetic NGP (No Ground Plane) antenna mount, a UHF antenna with threaded NMO base, and 15 feet of coax cable.

The POINT5 antenna optimizes your GMRS radio by delivering the best signal performance throughout the programmed channels.

"No Ground Plane" means the antenna does not have to be attached to a metal surface (such as a vehicle roof or larger body panel). Although using a ground plane is always better, this NGP antenna performs great for all uses, drivers, teams, and applications.

Molded high heat ABS mounting base features silver soldered connections, gold plated push pin contacts and O-ring.

The UHF antenna is already pre-tuned (cut) for UHF application. Simply order, mount, and ride!

UHF Range - 450-470
Connector Type - None
Color - Chrome Model(s)
Gain - 2.4 dB
UHF Bandwidth - 4 MHz
Power (watts) - 200
Whip Material - 17-7PH Stainless Steel
Whip Length - 12.5" UHF
Base Style - NMO Style
Mount Style - None
Connector Type - None

DO NOT OVER TIGHTEN ANTENNA TO NMO CONNECTOR
